Product description
A3 mATX is a chassis from Lian Li that combines a compact design with the ability to accommodate large components. This M-ATX mesh chassis with a volume of 26.3 liters supports both M-ATX and ITX motherboards as well as a GPU up to 415 mm. With its streamlined appearance and steel mesh side and top panels, the A3 mATX is designed for users who want to build a powerful and compact PC.The chassis construction includes a removable PSU bracket that allows the user to customize the placement of the power supply for optimal space. A3 mATX supports the installation of up to 360 mm radiators and up to 10 pieces of 120 mm fans for efficient cooling. This provides access to good airflow and thermal management. Additionally, the chassis is compatible with ATX, SFX, and SFX-L power supplies and can be mounted on both the side and front. The chassis is manufactured in collaboration with DAN Cases, which attests to its thoughtful design.
Summary
- Compact chassis with large capacity
- Accepts M-ATX and ITX motherboards
- Designed for gamers and PC builders
- Room for efficient cooling with up to 10 fans
- Removable PSU bracket for customized installation
Article number:
Our article number: 36703
Manuf. article number: G99.A3W-WD.00
Brand
Specifications
Front panel
| Audio output (3,5mm) | Yes |
| Microphone input (3,5mm) | Yes |
| USB 3.0/3.1 Gen 1 | 2 pcs |
| USB 3.1 Gen2 Type-C | 1 pcs |
Hard drive
| 2.5'' (standard) | 1 pcs |
| 2.5''/3.5'' (standard) | 2 pcs |
Performance
| Included fans | 2 pcs 140mm |
| Front fan spots | 3 pcs 120mm |
| Rear fan spots | 1 pcs 120mm |
| Fan spots top | 3 pcs 120mm |
| Fan spots side | 2 pcs 140mm |
Properties
| Type of side panel | Solid |
| Form factor | mATX, Mini-ITX |
| Side panel | Mesh |
| Motherboard support | mATX, Mini-ITX |
| Backlight | No |
| Colour | White |
| Dust filter | Yes |
| Expansion spots | 4 pcs |
Size & weight
| Max height CPU-cooler | 165 mm |
| Max length graphics card | 415 mm |
| Max length PSU | 220 mm |
| Width | 194 mm |
| Depth | 443 mm |
| Height | 321.5 mm |
| Weight | 500 g |
Warranty
| Manufacturer's warranty | 2 year warranty |
Water cooling
| Front radiator (max) | 360/280/240 mm |
| Radiator top (max) | 360/280/240 mm |
