FIIO K7 Headphone Amplifier - DAC/AMP

Product description

PC PeripheralsHeadsets & AudioExternal sound cards from FIIO

K7 headphone amplifier is a DAC/AMP from FIIO that offers high audio performance and flexibility in use. It is equipped with a THX AAA 788+ amplifier, capable of delivering 560mW at 300Ω and 2000mW at 32Ω with 1% distortion. This ensures that both low- and high-impedance headphones receive sufficient power, providing a music experience that is both deep and rich. K7 is designed to meet the needs of gamers and audiophiles with requirements for sound quality and versatility.

The device features a six-stage audio circuit with balanced analog and digital sections that minimize crosstalk, improving music playback. K7 is equipped with an AK4493SEQ DAC for high sound quality. Additionally, various music formats are easily handled by the XMOS XUF208 decoder which has dual clock management. The RGB indicator lights offer different colors and light effects that provide a visual experience during use. The power design of the K7 consists of several independent stages and an external 12V power supply, which provides stable and clean power for optimal listening. Safety systems for overheating and overload ensure that the device operates optimally under all circumstances. It has three output modes and two amplification levels to adapt to different headphones and audio needs.

Summary

• THX AAA 788+ amplifier.
• 560mW output at 300Ω, 2000mW at 32Ω.
• Designed for gamers and audiophiles.
• Six-stage audio circuit with balanced sections.
• RGB indicator lights with visual feedback.

Article number:

Our article number: 36763
Manuf. article number: K7

Audio output

	Mycket lågt (PO $ < 4.4mu ext{V}$, BAL $ < 7.7mu ext{V}$) ∣ THD+N: <0.0003% (6.35mm, 32 Ω)
	USB-B, Optisk, Koaxial, RCA Line In
	≥120dB (UAC) ∣ ≥128dB (AUX In)
	<1Ω (32Ω load)

Properties

	Balanserad (4.4mm): ≥2000mW @ 32 Ω ∣ 560mW @ 300 Ω
	Dubbla THX AAA 788+ (Fullbalanserad förstärkararkitektur)
	Dubbla AKM AK4493SEQ
	Hörlursutgångar: 4.4mm Balanserad, 6.35mm Obalanserad. Linjeutgångar: RCA Line Out, RCA Pre-Out (med volymkontroll).
	PCM 32bit/384kHz, DSD256 (via XMOS XUF208)
Colour	Black

Size & weight

Width	16,8 cm
Depth	5,5 cm
Height	12 cm
Weight	610 g

Warranty

Manufacturer's warranty

1 year warranty
